API Paradigms
#

REST (Representational State Transfer)
  • Characteristics:
    • Stateless architecture
    • Uses standard HTTP methods (GET, POST, PUT, DELETE)
    • Typically uses JSON for data exchange
    • Resource-oriented design
  • Pros:
    • Simple and widely adopted
    • Scalable and cacheable
    • Separation of client and server
  • Cons:
    • Potential for over-fetching or under-fetching data
    • Multiple round trips for complex data requirements
GraphQL
  • Characteristics:
    • Single endpoint for all operations
    • Strongly typed schema-based queries
    • Allows clients to request specific data
  • Pros:
    • Avoids over-fetching and under-fetching
    • Flexible data retrieval
    • Strong typing and introspection
  • Cons:
    • Complex queries can impact server performance
    • Always responds with HTTP 200 (error handling complexity)
    • Steeper learning curve
gRPC (Google Remote Procedure Call)
  • Characteristics:
    • Built on HTTP/2 protocol
    • Uses Protocol Buffers for serialization
    • Supports streaming (unary, server, client, bidirectional)
  • Pros:
    • High performance and low latency
    • Efficient binary serialization
    • Strong typing with protocol buffers
    • Supports multiplexing and server push
  • Cons:
    • Less human-readable (binary format)
    • Requires HTTP/2 support
    • Limited browser support
    • Steeper learning curve compared to REST

Use Cases

  • REST: Good for public APIs and CRUD operations
  • GraphQL: Ideal for complex data requirements and multiple client types
  • gRPC: Excellent for microservices and high-performance inter-service communication

REST
#

CRUD Operations
#

Basic operations of any data-driven application.

CRUD

HTTP mapping:

  • CREATE -> POST /api/products
  • READ -> GET /api/products
  • UPDATE -> PUT /api/products/:id
  • DELETE -> DELETE /api/products/:id

HTTP Methods
#

Method Safe Idempotent Cacheable Description
GET yes yes yes Retrieve a resource; never modifies state
HEAD yes yes yes Same as GET but response body is omitted; used to check existence or metadata
POST no no conditional* Submit data to create a resource or trigger an action
PUT no yes no Replace the entire resource with the request payload
PATCH no no conditional* Apply partial modifications to a resource
DELETE no yes no Remove the specified resource
OPTIONS yes yes no Return allowed methods and CORS headers for a resource
CONNECT no no no Open a tunnel to the target (used for HTTPS proxying)
TRACE yes yes no Echo the request back for diagnostic purposes

* POST and PATCH are only cacheable if the response includes explicit freshness headers (Cache-Control, Expires) and a Content-Location header matching the request URI. In practice this is rare, most POST/PATCH responses are not cached.

Safe - does not modify server state

GET /api/products/1 - is safe fetches a product. Call it once or a thousand times, the product is never changed. The server state is identical before and after.

DELETE /api/products/1 - is not safe, it changes state by removing the resource.

Idempotent - repeating the same request produces the same result

DELETE /api/products/1 - first call deletes the product and returns 204. Second call finds nothing and returns 404. The result differs, but server state is the same: the product is gone either way. That makes it idempotent.

POST /api/products - is not idempotent, each call creates a new product, so state accumulates with every request.

POST vs PUT vs PATCH
#

All three write to a resource, but differ in scope and idempotency.

Creates a new resource. The server assigns the ID, so calling it twice creates two resources.

POST /users
{ "name": "Alice", "middleName": "Jane", "email": "[email protected]" }
201 Created
{ "id": 42, "name": "Alice", "middleName": "Jane", "email": "[email protected]" }

Fully replaces a resource. Every field must be included, omitted fields are removed. Safe to retry; calling it multiple times with the same body has no additional effect.

PUT /users/42
{ "name": "Alice", "email": "[email protected]", "role": "admin" }
200 OK
{ "id": 42, "name": "Alice", "email": "[email protected]", "role": "admin" }

middleName was not included in the request and is removed from the resource.

Partially updates a resource. Only send the fields being changed; everything else is left untouched.

PATCH /users/42
{ "email": "[email protected]" }
200 OK
{ "id": 42, "name": "Alice", "email": "[email protected]", "role": "admin" }

Only email changed. name and role were not in the request but are preserved.

POST PUT PATCH
Target collection (/users) specific resource (/users/42) specific resource (/users/42)
Payload new resource data full replacement changed fields only
Idempotent no yes not guaranteed

Triggering Actions
#

REST is resource-oriented, but sometimes you need to trigger a process rather than create or modify a single resource. The pattern is to model the action as a resource, typically a job or task.

Instead of thinking “start a scan”, think “create a scan job”:

POST /scans
{ "targetId": "server-7", "type": "full" }
202 Accepted
{ "id": "scan-99", "status": "running", "targetId": "server-7" }

Signals that the request was received and work has begun, but is not yet complete. The client uses the returned id to poll for progress:

GET /scans/scan-99
{ "id": "scan-99", "status": "completed", "findings": 3 }

This keeps the API resource-oriented while cleanly modelling async side effects. POST is correct here because triggering the same action twice starts two jobs, it is intentionally not idempotent.

Communication Formats
#

JSON (JavaScript Object Notation)
  • Characteristics:
    • Lightweight data-interchange format
    • Human-readable and easy to understand
    • Based on a subset of JavaScript
  • Structure:
    • Uses key-value pairs and arrays
    • Supports nested structures
  • Data Types:
    • String, Number, Boolean, Array, Object, null
  • Pros:
    • Wide support across languages and platforms
    • Easy to parse and generate
    • Compact compared to XML
  • Cons:
    • No support for comments
    • Limited data type support (e.g., no date type)
  • Use Cases:
    • Web APIs, Configuration files, Data storage
XML (eXtensible Markup Language)
  • Characteristics:
    • Markup language that defines a set of rules for encoding documents
    • Self-descriptive and flexible
  • Structure:
    • Uses tags to define elements
    • Supports attributes within tags
  • Features:
    • Namespaces for avoiding name conflicts
    • DTD and XML Schema for defining structure
  • Pros:
    • Highly extensible
    • Strong support for metadata
    • Validation capabilities
  • Cons:
    • More verbose than JSON or Protocol Buffers
    • Can be overly complex for simple data
  • Use Cases:
    • SOAP web services, Configuration files, Data interchange in enterprise systems
Protocol Buffers (Protobuf)
  • Characteristics:
    • Binary serialization format developed by Google
    • Language-neutral, platform-neutral, extensible
  • Structure:
    • Defines message types in .proto files
    • Strongly typed fields
  • Features:
    • Backward and forward compatibility
    • Code generation for multiple languages
  • Pros:
    • Smaller size compared to JSON and XML
    • Faster parsing and serialization
    • Strict typing reduces errors
  • Cons:
    • Not human-readable in binary form
    • Requires additional tooling for development
    • Less flexible than JSON or XML for dynamic structures
  • Use Cases:
    • High-performance RPC systems (e.g., gRPC)
    • Inter-service communication in microservices
    • Data storage where space efficiency is crucial

Comparison

  • JSON: Best for web applications and APIs where human readability is important
  • XML: Suitable for complex data with metadata requirements and where extensive tooling support is beneficial
  • Protocol Buffers: Ideal for high-performance scenarios and when working with strongly typed data in multiple languages

Versioning
#

To ensure redesigns or changes don’t break existing functionality, implement versioned URLs for different API versions.

REST API Versioning
  • Current Version: /api/v2/products
    • Serves current clients
    • Latest features and improvements
  • Legacy Version: /api/v1/products
    • Serves older clients
    • May be deprecated in future
